Photometrics

• Dual 48W COB LED light source featuring:Cool white 5700K
  Warm white 2700K


• High CRI rating of 95+ for accurate colour rendering and natural skin tones

• Beam angle adjustable from 20° to 50°

• Field angle: 50°-67°

• Output:1,230 lux at 3m with 20° beam angle
  395 lux at 3m with 50° beam angle


• 80mm Fresnel lens

• PWM frequency: 1,200Hz

• LED lifespan rated at 50,000 hours

Effects

• Smooth 16-bit dimming from 0-100%

• Strobe effect from 1-25Hz

• Manual zoom adjustment from 20° to 50°

• Barn doors included

• Gel clip included

Power

• Universal 100-240V AC operation at 50/60Hz

• Power consumption: 75W

• True1 power input and output connectors

Control

• Operating modes:Manual
  Master/Slave
  DMX
  Optional WDMX


• DMX512 protocol support

• DMX channel modes:1-channel
  2-channel
  7-channel


• 4-button LCD control panel

• 5-pin XLR DMX input and output

Construction & Cooling

• Die-cast aluminium housing

• Matte black finish

• Fanless cooling system with temperature protection for silent operation

Physical Specifications

• Dimensions: 202 × 139 × 193mm

• Weight: 2.3kg
